SKU: LPF3024S-01

Spinning PF30

$89.00 USD
Select Spindle (mm)
Color
$89.00 USD

Information

This product features an innovative 20T internal locking design, significantly increasing the tool contact area and ensuring extremely even locking force, completely eliminating the nightmare of stripped threads on traditional bottom brackets. Combined with a revolutionary quick-release mechanism, it simplifies the previously cumbersome disassembly and maintenance process, drastically reducing preparation time. Precisely compatible with ISIS international standard crankshafts and bottom bracket systems, it's a direct upgrade without modification. This is not just a bottom bracket; it's the ultimate core for upgrading your cycle and pushing your limits. Weight reduction directly leads to top performance, allowing you to ride with effortless power.

Material: 7075-T6 Aluminium

Included: 24mm specification accessories,
2ps x cover.
2ps x bearing.
2ps x 1mm, 2ps x 5mm spindle spacer.

30mm specification accessories,
2ps x cover.
2ps x bearing.
2ps x 1mm spindle spacer.

29mm specification accessories,
2ps x cover.
2ps x bearing.
10ps x 1mm , 2ps x 0.5mm spindle spacer.

24/22mm specification accessories,
2ps x cover.
2ps x bearing.
2ps x 1mm, 2ps x 5mm spindle spacer.
2ps x spring spacer
Specifically designed for installing 22mm / 24mm spindle diameter cranks (SRAM / Truvativ GXP) the frames without the need for any adapters.

Features

Tapered Profile

Fun5 bearing technology not only enables automatic coaxialisation for improved power output. Its easy maintenance feature ensures that it can operate smoothly for extended periods, while angular contact further enhances its reliability and longevity.

The Art of Stability

The 20T internal locking mechanism not only has greater installation fault tolerance while maintaining a sleek appearance, but also features a Thread Together structure that prevents foreign objects from entering. This increases rigidity, enabling it to conquer more challenging terrains. This innovative design provides cyclists with greater confidence and control during rides, making it an ideal choice for adventurous and rugged terrain.

High-Speed Rolling

By integrating high sphericity steel balls and nano grease, this technology significantly reduces friction and enables high-speed operation, while maintaining exceptional waterproof capabilities. Cyclists can now enjoy a tight and efficient riding experience, regardless of the weather conditions, and achieve better performance and control on a wide variety of terrains.

Specifications

Item Bearing Shell DIA Shell Width Crankset Weight
LPF3024S Cartridge 46mm 68-73mm Shimano HTII 138.7g
LPF3024C Ceramic 46mm 68-73mm Shimano HTII 136.8g
LPF3029S Cartridge 46mm 68-73mm Sram DUB 170.1g
LPF3029C Ceramic 46mm 68-73mm Sram DUB 167.1g
LPF30S Cartridge 46mm 68-73mm 30mm axle crankset 168.3g
LPF30C Ceramic 46mm 68-73mm 30mm axle crankset 165.3g
LPF3022S Cartridge 46mm 68-73mm Sram Gxp 140.2g
LPF3022C Ceramic 46mm 68-73mm Sram Gxp 138.5g
